RC-A1-124X202mm-DS5X96 Led Module

Name: RC-A1-124X202mm-DS5X96 Led Module
Availability: InStock

Manufacturer : Sarnikon
Category : Outdoor Lighting LED Modules

Ideal LED module for park, garden, gas station, street and tunnel lighting
Low energy consumption, high efficiency and long life
homogeneous lighting
3 years warranty

Product Specs

Product code	Color Temperature	Total number of LEDs	Number of Parallel Arms	Number of LEDs connected in series	Luminous flux @ ts = 25 °C (lm)		Light Axis @ ts = 65 °C (lm)		Driving Current (mA)	min. Driving Voltage @ ts = 65 °C (V)	Max. Driving Voltage @ ts = 25 °C (V)	Max. Power (W)	Colour rendering index (CRI)
Operating mode at 350 mA
RC-A1-124X202-DS5X96-30	3000K	96	8	12	7096	8870	6600	8249	700	67	79	55	≥80
RC-A1-124X202-DS5X96-40	4000K	96	8	12	7096	8870	6600	8249	700	67	79	55	≥80
RC-A1-124X202-DS5X96-65	6500K	96	8	12	7096	9504	6600	8839	700	67	79	55	≥80
Operating mode at 500 mA
RC-A1-124X202-DS5X96-30	3000K	96	8	12	9139	11424	8499	10624	1000	67	79	79	≥80
RC-A1-124X202-DS5X96-40	4000K	96	8	12	9139	11424	8499	10624	1000	67	79	79	≥80
RC-A1-124X202-DS5X96-65	6500K	96	8	12	9139	12240	8499	11383	1000	67	79	79	≥80
Operating mode at 700 mA
RC-A1-124X202-DS5X96-30	3000K	96	8	12	12365	15456	11499	14374	1400	67	79	111	≥80
RC-A1-124X202-DS5X96-40	4000K	96	8	12	12365	15456	11499	14374	1400	67	79	111	≥80
RC-A1-124X202-DS5X96-65	6500K	96	8	12	12365	16560	11499	15401	1400	67	79	111	≥80
