PL1672UN

Single Lenses for Power LEDs; Ultra Narrow Punch Beam Lens
Single Lenses for Power LEDs
35.00 mm diameter – 20.71 mm height – Ultra Narrow Punch Beam Lens
MR11 Standard

MATERIAL:
PMMA

BENEFITS:
– LED chip projection on the target completely eliminated
– Clean spot, efficiency > 89%
– Optical grade PMMA
– 3 pins for precise and robust mounting
– FWHM = 3.5° for 1 mm2 chip area LEDs
– CBCP (Center Beam Candle Power) = 150 cd / lm
– Smallest shape factor lens (Diameter × FWHM / ChipSize)

TYPICAL APPLICATIONS:
– Façade lighting
– Indoor
– Indoor architectural and general lighting
– Indoor recessed luminaires
– Indoor spot
– Industrial Light – Commercial Light
– IR
– Office
– Outdoor
– Outdoor architectural
– Outdoor wall-type luminaires
– Security lighting
– Spot lighting and floodlights
– Stadium / sports arena lighting
– Table and floor lamps
– Task lighting
– Tracking systems
