LNR AL1 500X16 D28X72 1 | Sarnikon
LNR-AL1-500X16-D28X72
Manufacturer :Sarnikon
Category :Indoor Lighting LED Modules
Product Features
| Product code | Color Temperature | Total number of LEDs | Number of Parallel Arms | Number of LEDs connected in series | Luminous flux @ ts = 25 °C (lm) | Luminous flux @ ts = 45 °C (lm) | Drive Current (mA) | Min. Drive Voltage @ ts = 45 °C (V) | Max. Drive Voltage @ ts = 25 °C (V) | Max. Power (W) | Colour rendering index (CRI) | ||
| Operating mode at 350 mA | |||||||||||||
| LNR-500X16-D 28*35X72-30 | 3000K | 72 | 4 | 18 | 2486 | 2884 | 2425 | 28ç13 | 350 | 50,4 | 57,6 | 20,16 | ≥80 |
| LNR-500X16-D 28*35X72-40 | 4000K | 72 | 4 | 18 | 2586 | 3083 | 2522 | 3007 | 350 | 50,4 | 57,6 | 20,16 | ≥80 |
| LNR-500X16-D 28*35X72-65 | 6500K | 72 | 4 | 18 | 2586 | 3083 | 2522 | 3007 | 350 | 50,4 | 57,6 | 20,16 | ≥80 |
Note: The LED module is designed for use with a constant current driver.
-
