LF-AADxxx Series | Sarnikon
LF-AADxxx Series
Manufacturer :Lifud
Category :Constant Current/Indoor/Dimmable
1. DALl and PUSH DIM feature
2. Constant lumen, current tolerance max 3%
3. Output current adjustment with DIP Switch (in 50mA steps)
4. Logarithmic or linear DIM curve can be selected
5. Flicker-free dimming; flicker <1%
6. DIM range: 0%-100%; DIM depth: 0.1%
7. Suitable for Class II luminaires
Application Areas: Plant lighting, indoor office lighting, decorative lighting, commercial lighting, residential lighting
Certificates: DALI-2, ENEC, CE, CB, RCM, CCC
5 Years Warranty
2. Constant lumen, current tolerance max 3%
3. Output current adjustment with DIP Switch (in 50mA steps)
4. Logarithmic or linear DIM curve can be selected
5. Flicker-free dimming; flicker <1%
6. DIM range: 0%-100%; DIM depth: 0.1%
7. Suitable for Class II luminaires
Application Areas: Plant lighting, indoor office lighting, decorative lighting, commercial lighting, residential lighting
Certificates: DALI-2, ENEC, CE, CB, RCM, CCC
5 Years Warranty
Product Features
Model | Output Power (W) | Input Voltage Range (Vac) | Output Voltage Range (Vdc) | Output Current Range (mA) | Efficiency | Power Factor | Dimension (L*W*H)(mm) |
LF-AAD008-0350-42 | 8 | 220 – 240 | 9 – 42 | 100 – 350 | 76% (230Vac) | 0.90 (230Vac) | 142*29*20.5 |
LF-AAD008-0700-12 | 8 | 220 – 240 | 2 – 12 | 350 – 750 | 76% (230Vac) | 0.90 (230Vac) | 142*29*20.5 |
LF-AAD012-0400-42 | 12 | 220 – 240 | 9 – 42 | 150 – 400 | 82% (230Vac) | 0.90 (230Vac) | 122*40*25 |
LF-AAD020-0500-42 | 20 | 220 – 240 | 9 – 42 | 250 – 500 | 85% (230Vac) | 0.95 (230Vac) | 122*40*25 |
LF-AAD030-0750-42 | 30 | 220 – 240 | 9 – 42 | 400 – 750 | 85% (230Vac) | 0.95 (230Vac) | 141*46*27 |
LF-AAD040-1050-42 | 40 | 220 – 240 | 9 – 42 | 550 – 1050 | 87% (230Vac) | 0.95 (230Vac) | 141*46*27 |
