LF-GOExxxYV Series
Category : Constant Voltage/Outdoor
2. High efficiency (<93%)
3. Easy voltage adjustment with potentiometer
4. Lightning Protection: L-N: 6KV, L/N-PG: 8KV
5. IP67
Scope of Application: Outdoor Lighting, Residential Lighting, LED lightbox,.. etc.
Certifications: ENEC, CE, CB, UL, FCC, RCM
5 Year Warranty
Model+A3:H11A3:H20A3A3:H16 | Output Power(W) | Input Voltage Range (Vac) | Output Voltage Range (Vdc) | Output Current Range (mA) | Efficiency | Output Voltage Tolerance(Output Voltage Tolerance) | Dimensions(Dimension)(L*W*H)(mm) |
LF-GOE075YV012A | 60 | 100-180 | 12 | 0.24 – 5.0 | 86%(180Vac) | 92%-108% | 170*61*34 |
LF-GOE075YV012A | 75 | 220-277 | 12 | 0.24 – 6.25 | 87%(230Vac) | 92%-108% | 170*61*34 |
LF-GOE075YV024A | 60 | 100-180 | 24 | 0.24 – 2.5 | 87%(180Vac) | 92%-108% | 170*61*34 |
LF-GOE075YV024A | 75 | 220-277 | 24 | 0.24 – 3.125 | 88%(230Vac) | 92%-108% | 170*61*34 |
LF-GOE100YV012A | 75 | 100-180 | 12 | 0.24 – 6.25 | 87%(180Vac) | 92%-108% | 170*61*34 |
LF-GOE100YV012A | 100 | 220-277 | 12 | 0.4 – 8.34 | 89%(230Vac) | 92%-108% | 170*61*34 |
LF-GOE100YV024A | 75 | 100-180 | 24 | 0.24 – 3.125 | 87%(180Vac) | 92%-108% | 170*61*34 |
LF-GOE100YV024A | 100 | 220-277 | 24 | 0.24 – 4.17 | 89%(230Vac) | 92%-108% | 170*61*34 |
LF-GOE150YV012A | 100 | 100-180 | 12 | 0.4 – 8.34 | 88%(180Vac) | 92%-108% | 170*61*34 |
LF-GOE150YV012A | 150 | 220-277 | 12 | 0.4 – 11.5 | 93%(230Vac) | 92%-108% | 170*61*34 |
LF-GOE150YV024A | 100 | 100-180 | 24 | 0.24 – 4.17 | 88%(180Vac) | 92%-108% | 170*61*34 |
LF-GOE150YV024A | 150 | 220-277 | 24 | 0.4 – 6.25 | 93%(230Vac) | 92%-108% | 170*61*34 |
LF-GOE200YV012A | 150 | 100-180 | 12 | 0.4 – 12.5 | 88%(180Vac) | 92%-108% | 228*63*34 |
LF-GOE200YV012A | 200 | 220-277 | 12 | 0.4 – 16.67 | 93%(230Vac) | 92%-108% | 228*63*34 |
LF-GOE200YV024A | 150 | 100-180 | 24 | 0.4 – 6.25 | 88%(180Vac) | 92%-108% | 228*63*34 |
LF-GOE200YV024A | 200 | 220-277 | 24 | 0.4 – 8.34 | 93%(230Vac) | 92%-108% | 228*63*34 |
LF-GOE250YV024A | 200 | 100-180 | 24 | 0.4 – 8.34 | 88%(180Vac) | 92%-108% | 228*63*34 |
LF-GOE250YV024A | 250 | 220-277 | 24 | 0.4 – 10.42 | 93%(230Vac) | 92%-108% | 228*63*34 |
