LF-GOExxxYE YF Series
Manufacturer : Lifud
Category : Constant Current/Outdoor
1. 3-in-1 DIM Specification: 0-10V/PWM/Rx (For YF Models)
2. High efficiency (<94.5%)
3. Two Levels Flicker Free
4. Output current adjustment with potentiometer
5. Lightning Protection: 6KV/10KV
6. IP67
Fields of Application: Street lighting, tunnel lighting, greenhouse lighting, landscape lighting
Certifications: ENEC, CE, CB, RCM, CCC, FCC, UL
5 Year Warranty
Model+A3:I10A3:H21A3:H1A3:H8 | Çıkış Gücü (Output Power)(W) | Giriş Gerilim Aralığı (Input Voltage Range)(Vac) | Çıkış Gerilim Aralığı (Output Voltage Range)(Vdc) | Çıkış Akım Aralığı (Output Current Range)(mA) | Verimlilik(Efficiency) | Güç Faktörü (Power Factor) | Ölçüler(Dimension)(L*W*H)(mm) |
LF-GOE110YE/YF | 110 | 100 – 277 | 27 – 56 | 1500 – 3000 | 91% (230 Vac) | 0.95 (230 Vac) | 190*69*36 |
LF-GOE150YE/YF | 150 | 100 – 277 | 27 – 56 | 1800 – 4200 | 92% (230 Vac) | 0.95 (230 Vac) | 190*69*36 |
LF-GOE200YE/YF | 200 | 100 – 277 | 27 – 56 | 3000 – 5500 | 93.5% (230 Vac) | 0.95 (230 Vac) | 227*69*36 |
LF-GOE240YE/YF | 240 | 100 – 277 | 27 – 56 | 3500 – 6700 | 93.5% (230 Vac) | 0.95 (230 Vac) | 227*69*36 |
LF-GOE320YE/YF | 320 | 100 – 277 | 27 – 56 | 4000 – 8900 | 94.5% (230 Vac) | 0.95 (230 Vac) | 254*87*40 |
